Salient Features :
Applications :
Material of Constructions :
Motor Bush | LTB 4 IS: 318 |
Thrust Bearing | Carbon V/s SS |
Stamping | CRNO / CRC |
Motor | Aluminium Die Cast / Copper |
Rotot Shaft | SS 410 |
Stator Body | Cast Iron FG 200 |
Bowl / NRV Body | Cast Iron FG 200 |
Suction Housing | Cast Iron FG 200 |
Impellers | Cast Iron FG 200 |
Winding Wire | Poly Wrap EC Grade Copper |
OUTLET - 2.5"
VOLT - 415 ( -5% +3% )
MODEL | H.P. | STAGE |
PRICE FOR THREE PHASE |
Discharge In LPM | |||||
---|---|---|---|---|---|---|---|---|---|
200 | 400 | 600 | 800 | 1000 | 1200 | ||||
Total Head In Meter | |||||||||
V1 3 | 3.00 | 1 | 20880/- | 22 | 18 | 15 | 10 | 4 | 2 |
V1 5 | 5.00 | 1 | 23832/- | 28 | 25 | 20 | 12 | 6 | 3 |
V1 6 | 6.50 | 1 | 25872/- | 32 | 28 | 21 | 16 | 10 | 6 |
V1 7 | 7.50 | 1 | 28440/- | 36 | 30 | 25 | 18 | 12 | 8 |
OUTLET - 2.5"
VOLT - 415 ( -5% +3% )
MODEL | H.P. | STAGE |
PRICE FOR THREE PHASE |
Discharge In LPM | |||||
---|---|---|---|---|---|---|---|---|---|
350 | 400 | 600 | 800 | 1000 | 1350 | ||||
Total Head In Meter | |||||||||
V2 5 | 5.00 | 2 | 29472/- | 33 | 28 | 22 | 16 | 8 | 0 |
V2 6 | 6.50 | 2 | 30600/- | 35 | 30 | 24 | 17 | 10 | 4 |
V2 7 | 7.50 | 2 | 34020/- | 40 | 38 | 32 | 22 | 14 | 8 |
V2 7 | 7.50 | 3 | 36900/- | 50 | 48 | 36 | 26 | 18 | 10 |
V2 10 | 10.00 | 3 | 39600/- | 60 | 56 | 50 | 45 | 30 | 15 |
