Salient Features :
Applications :
Material of Constructions :
Motor Bush | LTB 4 IS: 318 |
Thrust Bearing | Carbon V/s SS |
Stamping | CRNO / CRC |
Motor Shaft | SS 420 |
Suction HSG / NVR Body | Cast Iron FG 220 |
Bowl | SS 304 |
Impellers | SS 410 |
Stator Body | SS 304 / SS 202 |
Pump Body | SS 202 |
Pump Sleeves | SS 410 Hard Chromed |
Pump Bush | Nitrile Rubber & LTB4 |
Fasteners / Hardwear | SS |
Winding Wire4 | Poly Wrap EC Grade Copper |
OUTLET - 2"
VOLT - 415 ( -5% +3% )
DUTY POINT HEAD PER STG. - 12 MT.
MODEL | H.P. | STAGE |
PRICE FOR |
PRICE FOR PUMP SET |
Discharge In LPM | |||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
200 | 170 | 150 | 145 | 130 | 120 | 80 | 55 | |||||
Total Head In Meter | ||||||||||||
K503006 | 3.0 | 6 | 13127/- | 39600/- | 18 | 30 | 42 | 54 | 66 | 72 | 84 | 90 |
K504008 | 4.0 | 8 | 16910/- | 44154/- | 24 | 40 | 56 | 72 | 88 | 96 | 112 | 120 |
K505010 | 5.0 | 10 | 20061/- | 48840/- | 30 | 50 | 70 | 90 | 110 | 120 | 140 | 150 |
K506012 | 6.0 | 12 | 25263/- | 53922/- | 36 | 60 | 84 | 108 | 132 | 114 | 168 | 180 |
K507515 | 7.5 | 15 | 30624/- | 62238/- | 45 | 75 | 105 | 135 | 165 | 180 | 210 | 225 |
K501020 | 10.0 | 20 | 37866/- | 72864/- | 60 | 100 | 140 | 180 | 220 | 240 | 280 | 300 |
K5012524 | 12.5 | 24 | 46218/- | 84810/- | 72 | 120 | 168 | 216 | 264 | 288 | 336 | 355 |
K501530 | 15.0 | 30 | 55671/- | 99264/- | 90 | 157 | 210 | 270 | 330 | 360 | 420 | 440 |
OUTLET - 2"
VOLT - 415 ( -5% +3% )
DUTY POINT HEAD PER STG. - 12 MT.
MODEL | H.P. | STAGE |
PRICE FOR |
PRICE FOR PUMP SET |
Discharge In LPM | |||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
240 | 225 | 200 | 185 | 160 | 145 | 110 | 90 | |||||
Total Head In Meter | ||||||||||||
K603005 | 3.0 | 5 | 12184/- | 37950/- | 15 | 25 | 35 | 45 | 55 | 60 | 70 | 75 |
K604007 | 4.0 | 7 | 15335/- | 42504/- | 21 | 35 | 49 | 63 | 77 | 84 | 98 | 105 |
K605008 | 5.0 | 8 | 16910/- | 45606/- | 24 | 40 | 56 | 72 | 88 | 96 | 112 | 120 |
K606010 | 6.0 | 10 | 20061/- | 50292/- | 30 | 50 | 70 | 90 | 110 | 120 | 140 | 150 |
K607512 | 7.5 | 12 | 25263/- | 57354/- | 36 | 60 | 84 | 108 | 132 | 144 | 168 | 180 |
K601016 | 10.0 | 16 | 31564/- | 66396/- | 48 | 80 | 112 | 144 | 176 | 192 | 224 | 240 |
K6012520 | 12.5 | 20 | 37866/- | 76692/- | 60 | 100 | 140 | 180 | 220 | 240 | 280 | 300 |
K601524 | 15.0 | 24 | 46218/- | 89364/- | 72 | 120 | 168 | 216 | 264 | 288 | 336 | 360 |
K6017527 | 17.5 | 27 | 50945/- | 101046/- | 85 | 150 | 205 | 262 | 319 | 347 | 402 | 460 |
K602030 | 20.0 | 30 | 55671/- | 108768/- | 90 | 150 | 210 | 270 | 330 | 360 | 420 | 450 |
OUTLET - 2"
VOLT - 415 ( -5% +3% )
DUTY POINT HEAD PER STG. - 12 MT.
MODEL | H.P. | STAGE |
PRICE FOR |
PRICE FOR PUMP SET |
Discharge In LPM | |||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
330 | 310 | 275 | 255 | 240 | 205 | 160 | 125 | |||||
Total Head In Meter | ||||||||||||
K803004 | 3.0 | 4 | 10685/- | 36498/- | 12 | 20 | 28 | 36 | 44 | 48 | 56 | 60 |
K804005 | 4.0 | 5 | 12548/- | 40920/- | 15 | 25 | 35 | 45 | 55 | 60 | 70 | 75 |
K805006 | 5.0 | 6 | 14196/- | 46440/- | 18 | 30 | 42 | 54 | 66 | 72 | 84 | 90 |
K806008 | 6.0 | 8 | 17492/- | 47784/- | 24 | 40 | 56 | 72 | 88 | 96 | 112 | 120 |
K807510 | 7.5 | 10 | 20788/- | 54516/- | 30 | 50 | 70 | 90 | 110 | 120 | 140 | 150 |
K801012 | 10.0 | 12 | 26136/- | 60324/- | 36 | 60 | 84 | 108 | 132 | 144 | 168 | 180 |
K8012515 | 12.5 | 15 | 31080/- | 69168/- | 45 | 75 | 105 | 135 | 165 | 180 | 210 | 225 |
K801518 | 15.0 |
18 |
35755/- | 80388/- | 54 | 90 | 126 | 162 | 198 | 216 | 252 | 270 |
K8017522 | 17.5 | 22 | 42616/- | 92334/- | 66 | 110 | 154 | 198 | 242 | 264 | 308 | 377 |
K802025 | 20.0 | 25 | 47560/- | 100914/- | 75 | 125 | 175 | 225 | 275 | 300 | 350 | 375 |
OUTLET - 2"
VOLT - 415 ( -5% +3% )
DUTY POINT HEAD PER STG. - 12 MT.
MODEL | H.P. | STAGE |
PRICE FOR |
PRICE FOR PUMP SET |
Discharge In LPM | |||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
425 | 390 | 360 | 310 | 275 | 245 | 190 | 140 | |||||
Total Head In Meter | ||||||||||||
K1003003 | 3.0 | 3 | 9559/- | 34650/- | 9 | 18 | 21 | 26 | 33 | 36 | 42 | 45 |
K1004004 | 4.0 | 4 | 11310/- | 37646/- | 12 | 20 | 28 | 36 | 44 | 48 | 56 | 60 |
K1005005 | 5.0 | 5 | 13060/- | 40788/- | 15 | 25 | 35 | 45 | 55 | 60 | 70 | 75 |
K1006006 | 6.0 | 6 | 14810/- | 44325/- | 18 | 30 | 42 | 54 | 66 | 72 | 84 | 90 |
K1007508 | 7.5 | 8 | 18310/- | 51810/- | 24 | 40 | 56 | 72 | 88 | 96 | 112 | 120 |
K1001010 | 10.0 | 10 | 21811/- | 57816/- | 30 | 50 | 70 | 90 | 110 | 120 | 140 | 150 |
K10012512 | 12.5 | 12 | 27364/- | 65208/- | 36 | 60 | 84 | 108 | 132 | 144 | 168 | 225 |
K1001515 | 15.0 |
15 |
32615/- | 76692/- | 45 | 75 | 105 | 135 | 165 | 180 | 210 | 180 |
K10017518 | 17.5 | 18 | 37866/- | 86922/- | 54 | 90 | 126 | 162 | 198 | 216 | 252 | 270 |
K1002020 | 20.0 | 20 | 41366/- | 94908/- | 60 | 100 | 140 | 180 | 220 | 240 | 280 | 300 |
K1002525 | 25.0 |
25 |
60318/- | 112596/- | 75 | 125 | 175 | 225 | 275 | 300 | 350 | 375 |
OUTLET - 2.5"
VOLT - 415 ( -5% +3% )
DUTY POINT HEAD PER STG. - 12 MT.
MODEL | H.P. | STAGE |
PRICE FOR |
PRICE FOR PUMP SET |
Discharge In LPM | |||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
525 | 500 | 450 | 425 | 380 | 345 | 260 | 220 | |||||
Total Head In Meter | ||||||||||||
K1254030 | 4.0 | 3 | 9874/- | 36828/- | 9 | 15 | 21 | 27 | 33 | 36 | 42 | 45 |
K1255004 | 5.0 | 4 | 11729/- | 40194/- | 12 | 20 | 28 | 36 | 44 | 48 | 56 | 60 |
K1256005 | 6.0 | 5 | 13585/- | 43956/- | 15 | 25 | 35 | 45 | 55 | 60 | 70 | 75 |
K1257506 | 7.5 | 6 | 15440/- | 49500/- | 18 | 30 | 42 | 54 | 66 | 72 | 84 | 90 |
K1251008 | 10.0 | 8 | 19151/- | 55572/- | 24 | 40 | 56 | 72 | 88 | 96 | 112 | 120 |
K12512510 | 12.5 | 10 | 22862/- | 63162/- | 30 | 50 | 70 | 90 | 110 | 120 | 140 | 150 |
K1251512 | 15.0 | 12 | 28624/- | 73194/- | 36 | 60 | 84 | 108 | 132 | 144 | 168 | 180 |
K12517514 | 17.5 |
14 |
32335/- | 81972/- | 45 | 75 | 105 | 135 | 165 | 180 | 210 | 225 |
K1252016 | 20.0 | 16 | 36045/- | 90288/- | 54 | 90 | 126 | 162 | 198 | 216 | 252 | 270 |
K1252520 | 25.0 | 20 | 52151/- | 106854/- | 60 | 100 | 140 | 180 | 220 | 240 | 280 | 300 |
OUTLET - 2.5"
VOLT - 415 ( -5% +3% )
DUTY POINT HEAD PER STG. - 12 MT.
MODEL | H.P. | STAGE |
PRICE FOR |
PRICE FOR PUMP SET |
Discharge In LPM | |||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
600 | 580 | 565 | 490 | 450 | 400 | 310 | 240 | |||||
Total Head In Meter | ||||||||||||
K1254030 | 3.0 | 2 | 8143/- | 33858/- | 6 | 10 | 14 | 18 | 22 | 24 | 28 | 30 |
K1255004 | 5.0 | 3 | 10060/- | 36676/- | 9 | 15 | 21 | 27 | 33 | 36 | 42 | 45 |
K1256005 | 6.0 | 4 | 11977/- | 42438/- | 12 | 20 | 28 | 36 | 44 | 48 | 56 | 60 |
K1257506 | 7.5 | 5 | 13895/- | 47850/- | 15 | 25 | 35 | 45 | 55 | 60 | 70 | 75 |
K1251008 | 10.0 | 7 | 17729/- | /- | 21 | 35 | 49 | 63 | 77 | 84 | 98 | 105 |
K12512510 | 12.5 | 8 | 19647/- | 60192/- | 24 | 40 | 56 | 72 | 88 | 96 | 112 | 120 |
K1251512 | 15.0 | 10 | 25533/- | 70422/- | 30 | 50 | 70 | 90 | 110 | 120 | 140 | 150 |
K12517514 | 17.5 |
12 |
29367/- | 79398/- | 36 | 60 | 84 | 108 | 132 | 144 | 168 | 180 |
K1252016 | 20.0 | 13 | 31285/- | 87252/- | 39 | 65 | 91 | 117 | 143 | 156 | 182 | 195 |
K1252520 | 25.0 | 17 | 39584/- | 102828/- | 51 | 85 | 119 | 153 | 187 | 204 | 238 | 355 |
OUTLET - 2.5"
VOLT - 415 ( -5% +3% )
DUTY POINT HEAD PER STG. - 12 MT.
MODEL | H.P. | STAGE |
PRICE FOR |
PRICE FOR PUMP SET |
Discharge In LPM | |||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
750 | 700 | 670 | 590 | 490 | 440 | 300 | 280 | |||||
Total Head In Meter | ||||||||||||
K2004002 | 4.0 | 2 | 8455/- | 35442/- | 6 | 10 | 14 | 18 | 22 | 24 | 28 | 30 |
K2006003 | 6.0 | 3 | 10529/- | 40854/- | 9 | 15 | 20 | 26 | 33 | 66 | 42 | 45 |
K2007504 | 7.5 | 4 | 12602/- | 46464/- | 12 | 20 | 28 | 36 | 44 | 48 | 56 | 60 |
K2001005 | 10.0 | 5 | 14676/- | 51348/- | 15 | 25 | 35 | 45 | 55 | 60 | 70 | 75 |
K20012506 | 12.5 | 6 | 16749/- | 57090/- | 18 | 30 | 42 | 54 | 66 | 72 | 84 | 90 |
K2001508 | 15.0 | 8 | 20895/- | 67518/- | 24 | 40 | 56 | 72 | 88 | 96 | 112 | 120 |
K20017509 | 17.5 | 9 | 22969/- | 74712/- | 30 | 45 | 63 | 81 | 99 | 108 | 126 | 135 |
K2002010 | 20.0 |
10 |
27095/- | 81312/- | 36 | 50 | 70 | 90 | 110 | 120 | 140 | 150 |
K2002010 | 25.0 | 12 | 30967/- | 96162/- | 39 | 65 | 91 | 117 | 143 | 156 | 182 | 195 |
